1.2V Rechargeable Ni Mh Battery 3600mAh 620mA 500 Cycles Life

Minimum Order Quantity : 5000PCS Price : Negotiated The Price
Packaging Details : Customer requirements Delivery Time : 30-45 work days
Payment Terms : T/T, D/P, D/A, L/C Supply Ability : 10000pcs/Month
Place of Origin: CHINA,GuangDong Brand Name: FUNPACK
Certification: CE ROHS UL Model Number: FP-NM-12

Detail Information

NAME: FP-NM-12 Capacity TBD: 3600mAh
Standard Current: 620mA Nominal Voltage: 1.2V
Cycle Life: 500 Cycles Impedance: 55mΩ
High Light:

3600mAh rechargeable ni mh battery

,

620mA rechargeable ni mh battery

Product Description

1.2 V Rechargeable Nimh Battery Pack 3600mAh Long Service Life High Powerful



Features:

Long cycle life, high reliability.
Small size, light weight, high energy density, environment friendly.
Wider working temperature range, excellent high and low tempera-ture performance
High efficiency, stable power supply, high power output, visual design.
High self-maintenance and strong environmental adaptability.



Basic specification:

Item

Specification

Nominal Voltage

1.2V

Capacity TBD

3600mAh(min)

Standard Current

Standard Charge Curreent:880mA(0.2C)

Standard Discharge Curreent:80mA(0.2C)

Suggestive Discharge Cut off Voltage

0.8V-1.0V

Charging Method

CV

Impedance

<55mΩ

Max. Pulse Discharging Current

2C

Cycle Life

After 500 cycles

Shipment Voltage

1.0V-1.2V



Main Applications :

Mainly used for  Vacuum Cleaner.

1.2V Rechargeable Ni Mh Battery 3600mAh 620mA 500 Cycles Life 0

FAQ:

Q1: Are you Factory,How long to make Battery Pack?
A: We are the Professional Battery Factory,we Need 30day around if we don't have stock of that model.Because need strictly

test and high temperature,high voltage life aging as well in every single Battery.That will takes a fixed date.
Q2:How to start the cooperate?
A: Lets start with the sample orders. In 5days will be ready the samples, then you test.We make the standard according the

data sheet which we give.Once you confirm the quality, we can talk for further.
Q3: What will be the packing?
A: We are using blister pallet packing in each battery pack. and then fold all packing in one ctn.
Q4: Can the connectors or PCB be customized?
A: Yes, we can choose the right connector according your requirement.Or help to match your device.
Q5: Is OEM/ODM battery pack available?
A: Yes, OEM/ODM battery packs are warmly welcome. Professional engineers provide technical support.

Q6: Do you have the documents required for battery shipments?
A: Yes, we have MSDS, UN38.3, etc. and other special files needed for shipments to some regions can also be secured.
