Pouch Polymer Ultra Thin Battery With PCB 7550mAh 7400mAh Capacity

Minimum Order Quantity : 10000PCS Price : Negotiated The Price
Packaging Details : Customer Requirements Delivery Time : 30-45 work days
Payment Terms : T/T, D/P, D/A, L/C Supply Ability : 5000PCS /Day
Place of Origin: CHINA Brand Name: FUNPACK
Certification: CE ROHS PSE Model Number: L28042

Detail Information

Battery Type: Li-ion Battery Voltage: 7.6V
Capacity: 7550mAh(Typ)57.28Wh/7400mAh(Min)56.24Wh Size: 171.7*166.5*8.1mm
Cell Weight: 306.23g Standard Current: 1480mA(0.2C)
High Light:

PCB Ultra Thin Battery

,

7400mAh Ultra Thin Battery

Product Description

Pouch Polymer Ultra Thin Battery With PCB 7550mAh 7400mAh Capacity



Product Description:

Standard Polymer battery pack 2s2p with 7.6V / 7550mAh

Worldwide approvals and certification of safety standards

No development costs, fast time-to-market

lithium-ion cells with the market’s highest energy density

Product materials can be customized according to customer requirements

Numerous and redundant safety features, e.g.

CUV (Cell Under Voltage): protection against deep discharge

COV (Cell Over Voltage): protection against over charge

OTD (Over Temperature in Discharge): Protection against overheating during discharging



High Light:

Rechargeable batteries have built-in high quality PCB board,

thermal protectors and circuit breakers,

effectively avoiding the over-charge, and short circuit.

High Capacity with Small Size



Product Parameters:

Item Specification
Wight 306.23g
Dimension 171.7*166.5*8.1mm
Charge Input Voltage 12V+/-5%
Charge Input Current 1A/1.4A
Discharge Output Voltage 12.1V+/-5%
Discharge Output Current 4200mAh,50Wh 1A/2A
Capactily 7550mAh(Typ)57.28Wh/7400mAh(Min)56.24Wh
Standard Current 1480mA(0.2C)
Maximum Charging Current 2220mA(0.3C)
3700mA(0.5C)
Maximum Discharging power 30W
Nominal Voltage 7.6V
Operating Voltage 6.0V
Operating Temperature Chargeing:0~+45℃
Discharging:-20~+55℃
Internal Resistance ≤150mΩ
Shipment Voltage 7.2V~7.56V
Pack Power Consumption Operating mode:1.2mA
Sleep mode:1000uA
Power Down mode:60uA



Main Applications:

For Promethean Board  Display Screen



Main Functions:

Lithium Polymer batteries make it possible for small objects to achieve intelligence. Bendable Lithium Polymer cells

open up new applications for lithium-ion batteries. For small, thin and flexible devices , Lithium Polymer battery can

provide a certain amount of electric energy to drive their functions of signal transmission or data acquisition. And

Lithium Polymer secondary battery allows charging and dischargingcycle, broadening the servicing life of

electronics products.



Pouch Polymer Ultra Thin Battery With PCB 7550mAh 7400mAh Capacity 0

Pouch Polymer Ultra Thin Battery With PCB 7550mAh 7400mAh Capacity 1

FAQ:

Q1: Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Customized is available.
Q2: What about the lead time?
A: Sample needs 7-12 days, mass production time needs negotiation.
Q3: How do you ship the goods and how long does it take to arrive?
A: We usually ship by JEC. It usually takes 13-15 days to arrive. Airline and sea shipping also optional.
Q4: How to proceed an order?
A: Firstly let us know your requirements or application. Secondly we quote according to your requirements or our
suggestions.  Thirdly customer confirms the samples and places deposit for formal order. Fourthly we arrange the production.
Q5: Is it OK to print my logo on product?
A: Ok, Need customer provide their packaging or we make neutral packaging.
Q6: Where can I get the price?
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us
or tell us in your email so that we’ll regard your inquiry priority.
