300mAh Consumer Electronics Battery Wearable Device Lithium Ion Polymer Battery With PCB

Minimum Order Quantity : 10000PCS Price : Negotiate the price
Packaging Details : Customer Requirements Delivery Time : 30-45days
Payment Terms : L/C, T/T, D/A, D/P Supply Ability : 10000PCS /Day
Place of Origin: CHINA Brand Name: FUNPACK
Certification: CE UL ROHS REACH Model Number: APP00311

Detail Information

Capacity:: 300mAh Standard Current:: 60mA
Nominal Voltage:: 3.85V-4.0V Impedance:: 350mΩ
Material: Polymer Weight: 6.0g
High Light:

300mAh Consumer Electronics Battery

,

PCB Consumer Electronics Battery

,

Wearable Device Lithium Ion Polymer Battery

Product Description

Polymerthe Lithium-ion Wearable Device Rechargeable Battery 300mAh 60mA With PCB


Features:
Rechargeable batteries have built-in high quality PCB board,
thermal protectors and circuit breakers,
effectively avoiding the over-charge, and short circuit.
High Capacity with Small Size


Product Parameters:

ItemSpecification
Battery Pack Type1S1P Embedded
Cell Type1S1P
Capacity300mAh (min)
Charging Current
Charge current 4.00V@ 0~15, Cut off 6.2mA60mA
Charge current 4.40V@15~45, Cut off 6.2mA310mA
Charge current 4.20V@45~60, Cut off 6.2mA310mA
Standard CurrentStandard Charge Current: 62mA
Standard Discharge Current: 62mA
Maximum Discharging Current
Discharge Current – @ -20~060mA
Discharge Current – @ 0~20155mA
Discharge Current – @ 20~60620mA
Nominal Voltage3.7V
Cut-off Voltage3.0V
Cycle lifeAfter 500 cycles (Under 23±2 )
Environmental using conditions
When stored within 1 Month (RSOC 50%) *2-20~ +45
When stored within 3 Months (RSOC 50%) *2-20~ +35
When stored within 12 Months (RSOC 50%) *2-20~ +25
Impedance340mΩ
WeightAbout 6.0g
Shipment Voltage3.65V ~ 3.80V
Size24*29*3.9mm


Main Applications :
Mainly used for Wearable Devices, Google Glass,iWatch,Solar glasses



Main Functions:
Lithium Polymer batteries make it possible for small objects to achieve intelligence. Bendable Lithium Polymer cells
open up new applications for lithium-ion batteries. For small, thin and flexible devices such as smart cards, trackers
and smart wearables, Lithium Polymer battery can provide a certain amount of electric energy to drive their functions
of signal transmission or data acquisition. And Lithium Polymer secondary battery allows charging and discharging
cycle, broadening the servicing life of electronics products.

300mAh Consumer Electronics Battery Wearable Device Lithium Ion Polymer Battery With PCB 0

300mAh Consumer Electronics Battery Wearable Device Lithium Ion Polymer Battery With PCB 1

FAQ:
Q1: Are you factory?
A:
Yes, we are professional manufacturer for polymer batteries since 2017
Q2: When you ship my order?
A: Normally 35-45days after payment confirmed, but it can be negotiated based on order qty and production schedule.
Q3: Can I get the pre-production sample?
A: Yes, we will send you sample for approval first, after you confirm, then we will start mass production order.
Q4: Can battery size customized available?
A: Yes, Please send up the capacity and max battery size, so that we can search our model for you.
Q5: How about the quality grantee period?
A: One Year.
Q6: How can you guarantee the production quality?
A:
We have more than 5 years experience of polymer battery production. Our production quality follow strict control program.
 We have 3 times inspection for finished product before package. All of our batteries are 100% tested and installed before shipment.
