3.7V Rechargeable Lithium Ion Battery Pack 7800mAh 8030mAh With PCB
Contact Person : YI QUAN
Phone Number : 13631634942
Whatsapp : +8613662635407
| Minimum Order Quantity : | 10000PCS | Price : | Negotiated The Price |
|---|---|---|---|
| Packaging Details : | Customer Requirements | Delivery Time : | 30-45 work days |
| Payment Terms : | T/T, D/P, D/A, L/C | Supply Ability : | 10000PCS /Day |
| Place of Origin: | CHINA,GuangDong | Brand Name: | FUNPACK |
|---|---|---|---|
| Certification: | CE ROHS UN38.3 MSDS | Model Number: | 3.7V-1S1P-1150mAH |
|
Detail Information |
|||
| Capacity: | 1150mAh | Nominal Voltage: | 3.7V |
|---|---|---|---|
| Maximum Discharging: | 2300mA(2.0C) | Maximum Charging: | 748mA (0.65C) |
| Over Discharge Current Protect: | 3.07(2.65 ~ 3.5)A | Size: | 68.5*64.4*16.2mm |
| High Light: | 920mAh Lithium ion Battery Pack,3.7V Lithium ion Battery Pack |
||
Product Description
High Safety Performance 3.7V 920mAh Customizable Battery For Medical Equipment
Product Description:
A quality cell, large capacity, lasting power
Intelligent protection plate, protect the battery but charge, but release, not short circuit
High quality wire, copper wire is not easy to break
Safety and environmental protection battery, non-toxic, harmless and pollution-free, green environmental protection
Product Parameters:
| Item | Specification |
| Cell Type | 1S1P |
| Capacity | 920mAh(Min.) |
| Standard Current | 230mA (0.2C) |
| Charge Voltage:4.10V@ 0℃ ~ 45℃, cut off 200mA Maintenance trigger voltage: 4.0V | 748mA (0.65C) |
| Charge Voltage:< 3.0V@ 0℃ ~ 45℃, | 230mA (0.2C) |
| Maximum Discharging Current*e | |
| Discharge Current – @ -20℃ ~ 0℃ | 230mA (0.2C) |
| Discharge Current – @ 0℃ ~ 40℃ | 2300mA(2.0C) |
| Nominal Voltage | 3.7V |
| Suggestive Discharge Cut off Voltage | |
| Discharge End of Voltage for Device set up | 3.2V ~ 3.4V |
| End of Voltage (Discharge) | 3.0V |
| Cycle life | After 500 cycles (Under 23±2 ℃) |
| Environmental using conditions | |
| When stored within 1 Month (RSOC 50% *a) *b | -20~ +50℃ |
| When stored within 3 Months (RSOC 50% *a) *b | -20~ +40℃ |
| When stored within 12Months (RSOC 50% *a) *b | -20~ +20℃ |
| Impedance | ≤160mΩ |
| Shipment Voltage | 3.5V ~ 3.9V |
| NTC | 10K±1%, Bv:3435K |
| Item | Specification | Parameter | Unit |
| Operating Temperature | 25 | ℃ | |
| Over Charge Voltage Protect | Detect Voltage | 4.28±0.015 | V |
| Delay Time | 0.7~1.3 | Sec | |
| Release | 4.28±0.02 | V | |
| Over Discharge Voltage Protect | Detect Voltage | 2.8±0.035 | V |
| Delay Time | 14~26 | mSec | |
| Release | 2.8±0.035 | ---- | |
| Over Charge Current Protect | Detect Current | Typ2.3(1.9~2.65) | A |
| Delay Time | 11~21 | mSec | |
| Release | Disconnect Charger | --- | |
| Over Discharge Current Protect | Detect Current | Typ. 3.07(2.65 ~ 3.5) | A |
| Delay Time | 8~16 | mSec | |
| Release | Remove R-Load or Connect Charger | --- | |
| Short Circuit | Detect Current | External Short | A |
| Delay Time | 180~400 | μSec | |
| Release | Remove R-Load or Connect Charger | --- | |
| Power Consumption | |||
| Operating Mode | 6.0(max) | μA | |
| Power Down Mode | 0.1(max) | μA | |
| PCM IR | 80 | mΩ |
Main Applications
Mainly used for Medical Equipment.
FAQ:
Q1: Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Customized is available.
Q2: What about the lead time?
A: Sample needs 7-12 days, mass production time needs negotiation.
Q3: How do you ship the goods and how long does it take to arrive?
A: We usually ship by JEC. It usually takes 13-15 days to arrive. Airline and sea shipping also optional.
Q4: How to proceed an order?
A: Firstly let us know your requirements or application. Secondly we quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly we arrange the production.
Q5: Is it OK to print my logo on product?
A: OK, Need customer provide their packaging or we make neutral packaging.
Q6: Where can I get the price?
A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price, please call us or tell us in your email so that we’ll regard your inquiry priority.
