Pure Sine Wave Off Grid Hybrid MPPT Solar Panel Inverter 51.2V 1kw 2kw 3kw 4kw 5kw 6kw

Minimum Order Quantity : 50PCS Price : Negotiated The Price
Packaging Details : Customer Requirements Delivery Time : 30-45 work days
Payment Terms : T/T, D/P, D/A, L/C Supply Ability : 500PCS /Day
Place of Origin: Made in CHINA Brand Name: FUNPACK
Certification: CE ROHS UN38.3 MSDS Model Number: GH3600TL/GH4600TL/GH5000TL

Detail Information

Battery Type: Lithium/Lead-Acid Nominal Battery Voltage(V): 51.2
Rated Power Output To Utility Grid(W)(W): 3600/4600/5000 Battery Voltage Range(V): 41.6~58.5
Max.Inut Power(W): 5200/6600/7000 Start-upVoltage(V): 150
MPPT Operating Voltage Range(V): 120-430
High Light:

MPPT Solar Panel Inverter


Hybrid MPPT Solar Panel Inverter


51.2V Solar Panel Inverter

Product Description

1kw 2kw 3kw 4kw 5kw 6kw 51.2V Pure Sine Wave off Grid Hybrid MPPT Solar Power Panel Inverter

Product Description Of White Solar Power Panel Inverter :

The working voltage range of MPPT is 120-430, the starting voltage is 150, the size is 350 * 580 * 230, and the maximum battery voltage is 51.2


Product Basic Information Of White Solar Power Panel Inverter:




Model GH3600TL GH4600TL GH5000TL
Battery Data
Battery Type Lithium Lithium Lithium
Nominal Battery voltage(V) 51.2 51.2 51.2
Max. Continuous Charging Current(A) 80 95 95
Max. Charge Power(W) 3600 4600 5000
Max. Discharge Power(W) 3600 4600 5000
PV String Input Data
Max.Input Power(W) 5200 6600 7000
Max.Input Voltage(V) 500 500 500
MPPT Operating Voltage Range(V) 120-430 120-430 120-430
Start-up Voltage(V) 150 150 150
Nominal Input Voltage(V) 360 360 360
Number of Strings per MPPT 1 1 1
AC Output Data
Rated Power(W) 3600 4600 5000
Nominal Output Current(A) 17.2 20 23.9
Nominal Output Voltage(V) 220/230/240 220/230/240 220/230/240
Nominal Output Freqency(Hz) 50/60 50/60 50/60
Mechanical Data
Dimension(W*H*Dmm) 350*580*230 350*580*230 350*580*230
Weight(kg) 25 25 25
Protection Level IP20 IP20 IP20
Installation Type Wall Installation with Wall Bracket

Main Applications Of White Solar Power Panel Inverter:

This product can convert unstable alternating current from solar energy into direct current that can be stored in a battery for battery use.

Pure Sine Wave Off Grid Hybrid MPPT Solar Panel Inverter 51.2V 1kw 2kw 3kw 4kw 5kw 6kw 4Pure Sine Wave Off Grid Hybrid MPPT Solar Panel Inverter 51.2V 1kw 2kw 3kw 4kw 5kw 6kw 5

Why choose us?

DONGGUAN FUNPACK ElEC CO., LTD. (referred to as FUNPACK) is a national high-tech company focusing on lithium-ion battery packaging,
design, production and sales.
The company was established in June 2017 with a registered capital of 5 million yuan. It is located in Qingxi Town, which is known as "the most
beautiful town in the country. The company has passed ISO 9001:2015 quality management system certification ISO14001:2015 environmental management system certification, QC080000 hazardous substance management system certification. The products have passed CE, CQC, RoHS, UN38.3, BIS and other certifications.
We adhere to the continuous independent innovation ability, excellent development and design ability and reasonable business positioning to provide customers with solutions to meet their different product needs. The company's business scope covers household energy storage, outdoor energy storage power supply, commercial energy storage system, photovoltaic energy storage system, security, medical treatment, precision instruments, intelligent travel, artificial intelligence, electric tools, unmanned aerial vehicles, ships 3C consumer electronics and other new energy fields.With efficient management.
Relying on efficient management, reasonable price and perfect techni- cal support,we strive to become a leader in the energy storage industry and creat high-quality energy storage products to bring users a better experience.


Q1. Are you factory?

A: Yes, we are professional manufacturer for polymer batteries since 2017.

Q2. What is your terms of payment?

A: T/T 30% as deposit, and 70% balance payment before shipment. We'll show you the photos of the products and packages before shipment.

Q3. Can I get the pre-production sample?
A: Yes, we will send you sample for approval first, after you confirm, then we will start mass production order.
Q4. Can battery size customized available?
A: Yes, Please send up the capacity and max battery size, so that we can search our model for you.

Q5. Where can I get the price?

A: We usually quote within 24 hours after we get your inquiry. If you are in urgent need of a price, please call us or let us know via Whatsapp or email and we will give priority to your inquiry.
