White Lithium Battery Split Phase Grid Connected Hybrid Solar Inverter 24V 48V

Minimum Order Quantity : 50PCS Price : Negotiated The Price
Packaging Details : Customer Requirements Delivery Time : 30-45 work days
Payment Terms : T/T, D/P, D/A, L/C Supply Ability : 500PCS /Day
Place of Origin: Made in CHINA Brand Name: FUNPACK
Certification: CE ROHS UN38.3 MSDS Model Number: OH3000TL/OH5000TL

Detail Information

Battery Type: Lithium/Lead-Acid Nominal Battery Voltage(V): 24/48
Rated Power(W): 3000/5000 Nominal Output Current(A): 13.6/21.7
Max.Inut Power(W): 2000/5500 Start-upVoltage(V): 30/150
MPPT Operating Voltage Range(V): 30-115/120-430
High Light:

Lithium Battery Hybrid Solar Inverter

,

Grid Connected Hybrid Solar Inverter

,

Split Phase Hybrid Solar Inverter

Product Description

OH3000TL OH5000TL white lithium battery split phase grid connected hybrid inverter 24V 48V


Product Description Of White 24V 48V Solar inverter :

The installation height is below 2000 meters above sea level, and wall brackets are used for wall installation. The size is 300 * 485 * 120, which communicates with the BOSS CAN



Product Basic Information Of White 24V 48V Solar inverter:​​

Model OH3000TL OH5000TL
Battery Data
Battery Type Lithium Lithium
Nominal Battery voltage(V) 24 48
Max. Continuous Charging Current(A) 120 80
Max. Charge Power(W) 3200 4500
Max. Discharge Power(W) 3000 5000
PV String Input Data
Max.Input Power(W) 2000 5500
Max.Input Voltage(V) 150 500
MPPT Operating Voltage Range(V) 30-115 120-430
Start-up Voltage(V) 30 150
Nominal Input Voltage(V) 100 300
Number of Strings per MPPT 1 1
AC Output Data
Rated Power(W) 3000 5000
Nominal Output Current(A) 13.6 21.7
Nominal Output Voltage(V) 220/230/240 220/230/240
Nominal Output Freqency(Hz) 50/60 50/60
Mechanical Data
Dimension(W*H*Dmm) 300*485*120 300*485*120
Weight(kg) 9 9.5
Protection Level IP20 IP20
Installation Type Wall Installation with Wall Bracket



Main Applications Of White 24V 48V Solar inverter:

This product can convert unstable alternating current from solar energy into direct current that can be stored in a battery for battery use.

White Lithium Battery Split Phase Grid Connected Hybrid Solar Inverter 24V 48V 4White Lithium Battery Split Phase Grid Connected Hybrid Solar Inverter 24V 48V 5

FAQ:

Q1. Are you factory?

A: Yes, we are professional manufacturer for polymer batteries since 2017.

Q2. What is your terms of payment?

A: T/T 30% as deposit, and 70% balance payment before shipment. We'll show you the photos of the products and packages before shipment.

Q3. Can I get the pre-production sample?
A: Yes, we will send you sample for approval first, after you confirm, then we will start mass production order.
Q4. Can battery size customized available?
A: Yes, Please send up the capacity and max battery size, so that we can search our model for you.

Q5. Where can I get the price?

A: We usually quote within 24 hours after we get your inquiry. If you are in urgent need of a price, please call us or let us know via Whatsapp or email and we will give priority to your inquiry.
