36V 24.5AH 48V17.5AH High Capacity Electric Bike Battery Pack 18650 Pack

Minimum Order Quantity : 500PCS Price : Negotiated The Price
Packaging Details : Customer Requirements Delivery Time : 30-45 work days
Payment Terms : T/T, D/P, L/C, D/A Supply Ability : 1000PCS /Day
Place of Origin: CHINA,GuangDong Brand Name: FUNPACK
Model Number: FP-JL-7S

Detail Information

Certification: CE/ROSH/UL/MSDS/UN38.3 Type: Lithium Ion
Application: Electric Bicycle Voltage: 36V 48V
Cycle Life: 500~1000 Cycles Capacity: 17.5Ah 24.5Ah Or Customized
Cell: Samsung/Panasonic/LG/Local Cell OEM: Acceptable

Product Description

High Capacity 36V 24.5AH 48V17.5AH Electric Bike Battery Pack 18650 Pack


Quick Details

Voltage:36V  48V                                                         Cycle life:500~1000 cycles

Nominal Capacity:17.5Ah  24.5Ah                              Modal  Cell : 18650 40pcs
Size: 426*90*87mm(Max)                                   Warranty: 12 months
Type: Lithium ion Battery 36V24.5Ah 48V17.5Ah


Basic specification:

Item Specification
Cell 70pcs 18650
Battery model FP-JL-7S
Max capacity 36V24.5Ah  48V17.5Ah
Charging port DC2.1 Opt.3Pin high current
Discharge port 6Pin
LED indicator single LED with three colours
L*W*H 426*90*87mm



Item Content Criterion


Over charge detection voltage 4.250±0.050V
Detection delay time 1.0±0.3S
Over charge release voltage 4.150±0.050V


Over discharge detection voltage 2.700±0.080V
Detection delay time 1.0±0.3S
Over discharge release voltage 3.000±0.100V
Rated operational current ≤20A


Primary over current detection current 50±5A
Primary detection delay time 800mS-1200mS
Secondary over current detection curren 100±10A
Secondary detection delay time 50mS-200mS
Short protection Detection condition >200A, 200uS-300uS
Protection yes Exist
Protective release condition Disconnect short circuit
Charging management Charging overvoltage protection voltage 43.5±0.4V
Rated charging current 3A
Software overcharges 4±0.2A
Detection delay time 300mS-600mS
Temperature protection Charging high temperature protection temperature 50±4℃
Charging protection recovery temperature 47±4℃
Discharge high temperature protection temperature 70±4℃
Discharge protection recovery temperature 55±4℃
Low temperature protect temperature of charging 0±4℃
Low temperature recovery temperature of charging 5±4℃
Interior resistance Main loop electrify resistance ≤60mΩ
The static current Since the power consumption ≤60.0uA
NTC YES Exist 10K±1% B3435±1%



36V 24.5AH 48V17.5AH High Capacity Electric Bike  Battery Pack   18650 Pack 0

36V 24.5AH 48V17.5AH High Capacity Electric Bike  Battery Pack   18650 Pack 1


According to Stardard Export Packing.

Carton box, wooden box, wooden pallet


OEM/ODM Service:

If you want to display your own brand logo in products, bags, labels or anywhere.

Our OEM and ODM services are ready to do it.


Delivery Time:

- Material Preparation Time: 7-15 days (or inventory)

- Production & Assembly Time 3-10 days

- Testing & Packaging Time: 2-10 days

- Total Delivery Time: 30-45days

- The faster delivery could be negotiable.
