48V 13S3P 15AH Electric Bicycle Battery Deep Cycle For E Bike
Contact Person : YI QUAN
Phone Number : 13631634942
Whatsapp : +8613662635407
| Minimum Order Quantity : | 500PCS | Price : | Negotiated The Price |
|---|---|---|---|
| Packaging Details : | Customer requirements | Delivery Time : | 30-45 work days |
| Payment Terms : | T/T, D/P, D/A, L/C | Supply Ability : | 500PCS /Day |
| Place of Origin: | Made in CHINA | Brand Name: | FUNPACK |
|---|---|---|---|
| Certification: | CE PSE ROHS | Model Number: | APP00293 |
|
Detail Information |
|||
| Capacity: | 12,800mAh(min) 13,000mAh(typical) | Charging Current: | 6,500mA |
|---|---|---|---|
| Nominal Voltage: | 28.8V | %22Suggestive Discharge Cut Off Voltage%22: | 25.6~27.2V |
| Cycle Life: | Sabout 500 Cycles (Under 25+2℃) | Impedance: | ≦150 MΩ |
Product Description
Product Description:
A quality cell, large capacity, lasting power. Intelligent protection plate, protect the battery but charge, but release, not short circuit
High quality wire, copper wire is not easy to break. Safety and environmental protection battery, non-toxic, harmless and pollution-free, green environmental protection.
Basic specification:
| Item | Specification |
| Battery Pack Type | 8S4P Removable |
| Cell | NCR18650BF |
| Capacity | 12,800mAh(min) 13,000mAh(typ) |
| Charging Current | 6,500mA |
| Standard Current | Standard Charge Current:2,600mA |
| Standard Discharge Current:2,600mA | |
| Maximum Discharging Current*d |
Discharge Current – @ -20 ~ 0℃ *a:2,600mA |
| Discharge Current – @ 0 ~ 60℃ *a:15,000mA | |
| Nominal Voltage | 28.8V |
| Cut-off Voltage | 24.0V |
| Suggestive Discharge Cut off Voltage |
25.6~27.2V |
| Cycle Life | After 300 cycles (Under 25+2℃) |
| Environmental Using Conditions | |
| When the battery is charged | 0~ +45℃ |
| When the battery is discharged | -20~ +60℃ |
| When Stored Within 1 Month (RSOC 50% *1) *2 | -20~ +50℃ |
| When Stored Within 3 Months (RSOC 50% *1) *2 | -20~ +40℃ |
| When Stored Within 12Months (RSOC 50% *1) *2 | -20~ +20℃ |
| Impedance | ≦150 mΩ |
| Weight | About 2500 g |
| Shipment Voltage | 27.2 ~ 28.8V |
Main Applications :
18650 lithium ion battery used in electric vehicles, electric tools and global consumer electronics,data communication, intelligent storage and other fields. Energy storage base station,scooter, electric bicycle,aerospace military products,ships and other high-end power battery.
FAQ:
Q1: Are you factory?
A: Yes, we are professional manufacturer for polymer batteries since 2017
Q2: What is MOQ for this product in your company?
A: 1000pcs.
Q3: When you ship my order?
A: Normally 35-45days after payment confirmed, but it can be negotiated based on order qty and production schedule.
Q4: Can I get the pre-production sample?
A: Yes, we will send you sample for approval first, after you confirm, then we will start mass production order.
Q5: Can battery size customized available?
A: Yes, Please send up the capacity and max battery size, so that we can search our model for you.
Q6: How about the quality grantee period?
A: One Year.
